Three different height settings for the transferter gripper bars allow sheets from 0.04 mm to 1 mm to be transported through the press gently and virtually contact-free over the air tracks.

With its ability to process a greater variety of substrate thicknesses, the ROLAND 500 can handle the work of two machines dedicated for paper and board respectively.

A wide range of optional Manroland applications including InlineCoater with automated plate tensioning, InlineFoiler and InlinePerfector allow for a wider range of jobs with higher quality finishes and enables print companies to position themselves at the top end of their market.

FEATURES AND BENEFITS
Highest quality output through flat, gentle sheet travel
Automated clamping and tensioning system for relief plates or coating blankets ensuring higher production efficiency
Maximum speed of 18,000 sph further enhances production efficiency
Highest levels of flexibility thanks to a substrate range of 0.04 mm to 1 mm
A variety of optional inline functions to help print companies achieve optimum return on investment
Format 0B Plus (590 x 740 mm)*
TECHNICAL SPECIFICATION
MAX. SPEED:
  • 16,000 sheets/h Max.
  • 18,000 sheets/h Max.*
SHEET SIZE:
  • 530 mm x 740 mm
  • 590 mm x 740 mm*
IMAGE AREA:
  • 520 mm x 740 mm
  • 580 mm x 740 mm*
SUBSTRATE THICKNESS RANGE:
  • 0.04 mm to 1.0 mm*
